GLORY 8
BARETONE AUDIO WIRELESS MICROPHONE | GLORY 8

Main Technical
- Transmitter Technical Specifications
- Frequency Range: 677.7 - 696.3MHz
- Number of Channels: 16 (conservative value) Each time pairing, the ID code changes randomly, within the frequency range set by the manufacturer
- Oscillator mode: DSP chip frequency lock
- Frequency Stability: ±10ppm
- Rf Power: 10dBmThe Frequency: 40-18000Hz
- Distortion Degree: ≤0.5%
- Battery Specifications: 1.5V/AA Size Alkaline battery
- Continuation time: 4-8 hours (depending on battery type and capacity)

Receiver Technical
- Frequency Range: 677.7-696.3MHz
- Number of Channels: 16 (conservative value) Each time pairing, the ID code changes randomly, within the frequency range set by the manufacturer
- Oscillator Mode: DSP chip frequency lock
- Rate Stability: +10ppm
- Receiving Sensitivity: -95 ~ -71dBm
- The tone frequency ranges from 40 to 18000Hz
- Distortion Degree: ≤0.5%
- Signal to Noise Ratio: ≥90dB
- Audio Output: 300mv(Max)

Handheld Transmitter
- Frequency Range: 2412-2484MHz
- Frequency Stability: 10PPM (-10 - 50°C)
- Rf Power: ≥10mW
- Frequency Response: 40Hz-18KHz
- Distortion Degree: ≤0.5%
- Modulation Mode: DSP
- Bandwidth: 950KHz
- Operating Voltage: 3.7V/5V
- Working Current: 80mA

Receiving Host
- Frequency Range: 2412-2484MHz
- Frequency Stability: 10PPM (-10-50°C)
- Sensitivity: -92 dBM - SNR: S/N≥90DB
- Frequency Response: 40Hz-18KHz
- Distortion Degree: ≤0.5%
- Audio Output: 350mv(Max)
- Operating Voltage: 3.7V/5V
- Working Current: 70mA
